Key Features
- Conical nozzle for consistent, repeatable bead shape
- Adjustable dispensing volume
- Built-in heating block & RS232 interface
- Adjustable screw speed for flexible process control
- Multiple alloy material options for fluid-contact parts
- Motor option: AC servo motor
- TC-pattern screw structure — optimized cost-performance balance
- Signal-controlled operation, compact mounting footprin
Compatible Materials
Designed for thermal conductive gel, high-filler thermal grease, sealant, silicone, solder paste, high-viscosity structural adhesive, and other medium-to-ultra-high-viscosity paste fluids with solid fillers.
Typical Applications
- Heavy coating & large-area potting
- Sealing filling
- New-energy / power modules
- Automotive electronics
- Photovoltaic manufacturing
- Semiconductor packaging & 5G components
- Camera modules, magnetic motors, voice coils
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | TD-SPG01 |
| Fluid Inlet | Luer connector |
| Screw Specification | TBS-40 / TBS-45 / TBS-60 / TBS-80 |
| Voltage | AC 220V, 50/60 Hz input |
| Trigger Circuit | 0V contact or 5–24 VDC signal |
| Mounting | Valve-body mounting holes |
| Viscosity Range | 6,000 – 1,300,000 cps |
| Repeatability | ±1.0% |
| Air Pressure | 0.6 MPa |
| Wetted Parts Material | SUS304 stainless steel |
Outline Dimensions Refer to the engineering drawing below for detailed layout dimensions (mm).
Why Choose the TD-SPG01
With its modular quick-disassembly design, the TD-SPG01 is easy to clean and maintain — minimizing downtime. The wear-resistant alloy screw assembly is built for long-time continuous mass production, making it a reliable choice for high-volume dispensing lines in new-energy, automotive electronics, and photovoltaic industrie
